Dual motor triple stage
Introducing our Triple Stage Dual Motor Sit-Stand Desk Frame—a high-performance, versatile solution for creating an ergonomic workspace. With a triple-stage design for extended height range and dual motors for stability and power, this desk frame is ideal for a dynamic and professional office environment.
Key Features:
·
Extended Height Adjustment: Experience a wide range of adjustability with a height range of 620mm to 1270mm, allowing you to seamlessly transition from sitting to standing for a healthier work posture.
·
·
Adjustable Width: The frame supports tabletops with a width range of 964mm to 1600mm, offering flexibility to fit different desk sizes.
·
·
Fast & Quiet Dual Motors: Equipped with dual motors, this frame ensures smooth and rapid adjustments at a speed of 35mm/s, with noise levels kept under 50dB to minimize disruptions.
·
·
Heavy-Duty Load Capacity: Constructed from durable Q235 Steel, the desk frame can support up to 120kg (265lbs), making it suitable for large desktops and professional setups.
·
·
Advanced Control Panel: Features an intuitive control panel with four programmable height memory settings, allowing you to save and quickly switch between preferred desk heights. Includes additional Metric and Inch Switch for precise adjustments.
·
·
Built-in Safety Features: Equipped with Anti-Collision Technology, Overheat/Overload Protection, and Leg Unbalance Protection for safe and reliable operation.
·
Specifications:
· Height Range: 620-1270mm
· Width Range: 964-1600mm
· Adjustment Speed: 35mm/s
· Noise Level: ≤50dB
· Weight Capacity: 120kg (265lbs)
· Material: Q235 Steel
· Input Voltage: AC 110V-220V
· Output Voltage: DC 24V
· Duty Cycle: Max. 10%
· Frame Weight: Net weight: 25kg, Gross weight: 27kg
· Recommended Tabletop Size: 1200-1800mm
